Extend Your Wi-Fi Signal with a Powerline Adapter

Add to WishlistAdded to wishlistRemoved from wishlist 0

Is It Time For A Powerline Adapter?

Are you having difficulties extending your WiFi coverage? A Powerline Adapter may be the answer.

If your home contains a lot of brick, concrete, and metal you’re going to have difficulties getting WiFi coverage throughout your home. Unfortunately, WiFi does not travel through brick, concrete, or metal. Even if you try WiFi extenders and Mesh you may still end up frustrated.

It may seem like the only option is to run ethernet cables through your walls and that can be expensive, messy, and even dangerous.

Thankfully, there’s another technology called Powerline that may be just what you’re looking for. A Powerline Adapter uses the existing electrical wiring in the walls of your home as network cabling.

Your first reaction to hearing about Powerline may be, “Oh well that sounds kind of dangerous!” but actually it’s perfectly safe.

Using Powerline Adapters – Video

In this article, we’ll be using a TP-Link Powerline Adapter to demonstrate Powerline as a way to extend your home wireless network.

When shopping for powerline adapters you’re going to notice very little in the way they name these things that resembles the English language. You’ll see some pictures some numbers and letters that don’t make a whole lot of sense.

TP-Link Powerline AV600

For example, this is the “TP-Link AV-600 300 Mbps” adapter. Say what? OK, so what does that mean? You’re probably used to seeing an “N” or “AC” followed by megabits per second on other Wi-Fi devices.

So what does the “AV 600” part mean? The reason “AV 600” is a separate number from the “300 Mbps” part is that “AV” designates the Powerline rating. The other number is the Wi-Fi rating.

TP-Link Powerline Adapter AV Rating

A Powerline Adapters AV rating can start at 300Mbps and go all the way up to 2100Mbps. Obviously the faster this rating the more expensive the powerline wi-fi adapter.

Here’s another adapter (Below.) It has a power line maximum speed of 1300 Mbps and maximum wi-fi speed of AC 1200 Mbps. It also has dual-band wi-fi built-in.

Amazon

Last updated on January 31, 2023 9:47 pm

This Powerline adapter below has no Wi-Fi and is specially designed to provide only very fast Powerline and Ethernet speeds.

Amazon

Last updated on January 31, 2023 9:47 pm

One of the most popular Powerline adapters manufacturers is TP-Link. They like to start you off with a “Starter Kit.” Starter Kits usually come with one adapter and one extender.

You can then expand your powerline network with other individual extenders if you want.

Amazon

Last updated on January 31, 2023 9:47 pm

When you get a powerline starter kit it will typically come with an adapter and an extender. Typically you’ll connect the adapter directly to one of the LAN ports in your wireless router and then “pair” the adapter and the extender.

Once these two have identified and are communicating with each other you can basically take the extender and put it anywhere in your home with an electrical outlet.

Depending on the quality of the wiring in your home, the two will be able to communicate. You’ll be able to connect other devices in your home either with Ethernet or Wi-Fi using the Powerline Wi-Fi extender.

Unfortunately, there are a lot of things that can go wrong here. If you have an older home the wiring in your home may not be able to provide a good connection between the adapter and the extender.

Also, if you have a larger home with several breakers and circuits the signal may not be able to jump from one circuit to the other. There’s really no way to predict whether a Powerline WiFi extender will work for you other than to take one home and try it. Save your receipts!

Tech Skills For The “Home IT Guru”

All Categories
Computer Basics
Computer Hardware
Computer Repair
Ethical Hacking
Home Automation
Home Networking
Microsoft Office
Office Productivity
Technical Skills
Website Building
Ethical Hacking
4.64
$94.99 $15
7096670 9d1a 5
VERY IMPORTANT: This course provides access to Hackers Academy labs. You will be required to create an account on Hackers Academy website. Short, c...
5 total hours
9932214 70cc 3
With millions of Alexa devices being sold, learning to build Custom Alexa Skills is becoming a highly sought after skill by employers. Electronics ...
4 total hours
14330204 bca7
SmartHomes are no longer just for the tech elite. They aren’t for rich home owners or for just the technical wizards. SmartHomes are here tod...
3.5 total hours
6956218 3564 4
Welcome to my WiFi cracking course where you’ll learn how to crack the key and get the password to WiFi networks weather they use WEP, WPA or...
6 total hours
33944616 a1bd 2
Hi there,Welcome to Wi-Fi Hacking and Wireless Penetration Testing CourseWEP, WPA/WPA2, WPS Cracking, Wifi Recon & Password cracking.Learn how ...
4 total hours
38516954 b11c 3
Just updated with all modern ethical hacking tools and best practices for 2023! Join a live online community of over 900,000+ students and a course...
28.5 total hours

Disclosure: We are a participant in the Udemy Affiliate Program, an affiliate advertising program designed to provide a means for our site to earn fees by linking to Udemy.com

Pairing Vs Cloning

Many Powerline extender kits will offer different ways to hook them up. The TP-Link AV 600 offers the option of “pairing” or “cloning.” This can cause a lot of confusion so let me break it down for you.

When you use the pairing button on the adapter and the extender these two devices will end up on the same network as each other but on a different network than the wireless router and your other devices.

That means you’ll have to type in a completely different network name (SSID) and password to connect to the extender.

Pairing Your Powerline Extender

Of course, you should be able to go into the extender’s web interface and change this if you want to.

The other option is to “clone” the extender directly to the wireless router just like you would with a wi-fi extender. In this case, the extender and the router end up on the same exact network. I’ll get into the specifics of this setup below.

cloning powerline extenders

One thing you want to look out for when using Powerline adapters is that you don’t want to connect them to power strips. The way electrical current travels through power strips and surge protectors can confuse and degrade the performance of a power line extender.

When you’re setting up your Powerline adapters it’s perfectly fine to plug them both into the same power strip but once they’re paired up you don’t want to keep the adapter or the extender plugged into a power strip.

Pairing Your Powerline WiFi Extender

To pair your adapter with the extender you simply plug the adapter into a WAN port on your wireless router, plug the extender into an outlet that’s really close by, and then hit the little pair button on the bottom or the side of both of the devices within two minutes of each other.

push powerline extenders pair button

Once the power lights on the adapter and the extender are solid green they’re connected and ready to use. You’ll be able to place your extender anywhere in the home you want and connect using the SSID and passphrase found on a sticker on the side of the device.

You’ll need to manually switch from the wireless router SSID and the extender SSID until you go into the web interface of the extender and change the SSID and passphrase to match your wireless router

Cloning Your Powerline Adapter To Your Router.

To clone the Powerline WiFi extender with the router we don’t connect the adapter right away. Instead, set it aside and hit the “clone button” on the extender and the WPS button on the wireless router within two minutes of each other.

clone powerline extender with wireless router

The cloning process will copy the SSID and passphrase settings from the wireless router to the extender. This puts the Powerline extender on the same wireless network as the router and all your devices!

Once it’s done you can connect the adapter to a LAN port in the wireless router and plug it into an electrical wall outlet and the adapter will automatically create a connection with the extender. You can then move the extender to an area of the house that needs wi-fi coverage.

Any devices that were connected to the wireless router before should be able to automatically connect to the Powerline WiFiextender. To add additional extenders simply use the pairing button on the new extender and pair it up with either the original extender or the adapter. This may vary with different models.

Setting up a Powerline adapter may not always go as smoothly as reading this article or watching a Youtube video but once you get through it you may very well have all the WiFi connectivity you need in all the nooks and crannies of your home without breaking the bank.
